Interferometer
Fizeau Interferometer (피조 간섭계)
Simple configuration and short interference optical path length are less susceptible to vibrations
and temperature fluctuations than other two interferometers, providing stability.
Used for observation of surface accuracy of a reflector.
Note that the intensity of reflected light from the measuring surface is not the same as that from the reference surface,
resulting in poor contrast of interference fringes compared to other interferometers.
| Product Name | Part Number | Quantity | Optical Axis Height [mm] |
| Laser Components | IFC2-L | 1 | 171 |
| Spatial Filter Component | IFC2-SF | 1 | 165 |
| Collimator Lens Component | IFC2-CL | 1 | 160 |
| Mirror Component | IFC2-M | 1 | 173 |
| Beamsplitter Component | IFC2-BS | 2 | 178 |
| Screen Component | IFC2-SC | 1 | 222.5 |
Screen 대신 카메라를 사용할 수 있음.
