Laser
| Model | Wavelength [nm] |
Min. ouput power free beam [mW] |
Beam Diameter [mm] |
|
|---|---|---|---|---|
| LGK 7650-02 | 632.8 | 0.5 | 0.49 | polarized |
| LGK 7650-03 | 632.8 | 0.5 ... 1 | 0.49 | laser class 2, polarized |
| LGK 7655* |
632.8 | 0.6 | 049 | |
| LGK 7655 S* | 632.8 | 1 | 0.49 | |
| LGK 7607* | 632.8 | 2 | 0.7 | 2 longitudinal modes |
| LGK 7608* | 632.8 | 1.5 | 0.63 | |
| LGK 7608 P | 632.8 | 1.5 | 0.63 | polarized, without sidelines |
| LGK 7610* | 632.8 | 2 | 0.63 | |
| LGK 7610 H* | 632.8 | 2 | 0.63 | with heater foil |
| LGK 7610 P | 632.8 | 2 | 0.63 | polarized, without sidelines |
| LGK 7672* | 632.8 | 2 | 0.75 | |
| LGK 7634 | 632.8 | 2 | 0.75 | polarized |
| LGK 7634 L | 632.8 | 2.2...3.2 | 0.75 | polarized |
| LGK 7637 | 632.8 | 3.5...3.8 | 0.49 | without sidelines |
| LGK 7627-08 | 632.8 | 5 | 0.8 | |
| LGK 7628 | 632.8 | 5 | 0.8 | polarized |
| LGK 7628 L | 632.8 | 5.5...7.5 | 0.8 | polarized |
| LGK 7621 MM | 632.8 | 5 | 1.4 | multimode |
| LGK 7627 MM | 632.8 | 10 | 0.7 | multimode |
| LGK 7653-08 | 632.8 | 10 | 0.7 | |
| LGK 7654-08 | 632.8 | 10 | 0.7 | polarized |
| LGK 7654-13 | 632.8 | 10 | 0.7 | polarized |
| LGK 7665 | 632.8 | 15 | 1 | |
| LGK 7665 P | 632.8 | 15 | 1 | polarized |
| LGK 7665-18 | 632.8 | 18 | 1 | |
| LGK 7665 P18 | 632.8 | 18 | 1 | polarized |
| LGK 7665-20 | 632.8 | 20 | 1 | |
| LGK 7512 P | 594 | 2 | 0.79 | polarized |
| LGK 7786 P50 | 543 | 0.5 | 0.85 | polarized |
| LGK 7786 P75 | 543 | 0.75 | 0.85 | polarized |
| LGK 7786 P100 | 543 | 1 | 0.85 | polarized |
| LGK 7786 P100-03 | 543 | 1 | 0.85 | polarized |
| LGK 7786 P120 | 543 | 1.2 | 0.85 | polarized |
| LGK 7786 P150 | 543 | 1.5 | 0.85 | polarized |
| LGK 7786 PD1 | 543 | 1 | 0.85 | polarized |
| LGK 7785-100 | 543 | 1 | 0.88 | |
| LGK 7785-150 | 543 | 1.5 | 0.88 | |
| LGK 7785-200 | 543 | 2 | 0.88 | |
| LGK 7785-250 | 543 | 2.5 | 0.88 |
